HFi Series 2-Channel Class A/B Car Amplifier
RMS Power Rating:
4 ohms: 100 watts x 2 chan.
2 ohms: 200 watts x 2 chan.
Bridged, 4 ohms: 400 watts x 1 chan.
Max power output: 400 watts
Pulse Width Modulated (PWM) MOSFET power supply
LED power (blue) and protect (red) indicators
Variable Bass Boost (0 to +12 dB bass boost at 45 Hz)
Blue illuminated Hifonics badge
Soft start sound function
2/1 channel operation
Preamp RCA outputs to daisy chain multiple amps
4-Way System Protection circuitry (thermal, overload, DC, and speaker short protection)
Tri-mode speaker operation
Heavy duty aluminum alloy vented heatsink for maximum heat dissipation
Silver nickle-plated RCA level inputs
Silver nickle-plated screw terminals
Input sensitivity:
Variable level: 200mV-6V
Variable high-pass filter (60-12,000 Hz, 12 dB/octave)
Variable low-pass filter (30-250 Hz, 12 dB/octave)
Damping factor: >180
Frequency response: 30-12,000 Hz
Dimensions: 9-15/16"L x 8-13/16"W x 2-7/16"
